| Type of AC : |
Split / Window/Light Commercial/VRF/Chiller ; |
Details |
Split |
| Fixed Speed / Inverter |
Details |
Fixed Speed |
| Cool only/ Heat & cool |
Details |
Cool only |
| Capacity: |
Cooling capacity |
BTU |
12000 BTU/HR |
| Power supply |
Rated Voltage |
Volts |
220-240 V |
| Rated frequency |
Hz |
50Hz |
| Running condition |
Withstanding Operating conditions : IDU |
°C |
16-31 |
| Withstanding Operating conditions : ODU |
°C |
20-43 |
| Cooling Area |
sq.ft |
90- 120 |
| Lowest running voltage |
Volts |
165 |
| Highest running voltage |
Volts |
264 |
| Cooling |
Capacity at rated condition (If required) |
Watt |
5275 |
| Power consumption in rated condition |
Watt |
1650 |
| Cooling data |
SEER/EER/COP (If any special requirement) |
kWh / kWh |
2.77 |
| Cooling Input Current |
A |
8.25 |
| Max. Input Current |
A |
14.10 |
| General |
Indoor side air flow (Max) |
m3/h |
870 |
| Indoor side noise level (Max) |
dB(A) |
47 |
| Dimensions (L*W*H) |
mm |
947*321*232 |
| Packing (L*W*H) |
mm |
1025*400*300 |
| Weight : Net & Gross |
Kg |
12.5±0.5 & 15.78±0.5 |
| Motor |
Motor Type : Single Phase Induction |
Details |
Induction (PG) |
| Motors Mechanical output Wattage |
Watt |
35 |
| Capacitor |
uF |
2 |
| Indoor Fan speed (Turbo) |
r/min |
1200 |
| Thermal protector |
Yes/ No |
yes |
| Fan |
Dimensions (Dia* Length) |
mm |
Φ108, L- 700±1 |
| Material of Blades |
Details |
SAN 30% GF |
| Evaporator |
Rows * Tubes |
No’s |
2*18 |
| Tube pitch (a) x row pitch (b) |
mm |
21 x 12.7 |
| Coil length |
mm |
755 |
| Tube specification |
mm |
ODΦ7.0 x 0.25 x0.18 IGT |
| Tube Material & Grade |
Details |
DHP COPPER, C12200 |
| Fin spacing |
mm |
1.2 |
| Fin type (Bare or Golden/Blue/Silver Coated) |
Details |
Golden Coated |
| Fin Material |
Details |
Aluminum |
| Control board |
Transformer Base/ SMPS Base |
Details |
SMPS |
| PU/ Protective layer |
Details |
PU |
| EMI/EMC compatible |
Details |
EMI |
| Wi-Fi support , Connectivity Module inbuilt / Separate module |
Details |
NO |
| Display PCB : LCD Display/ 7Seg Display/ LED indicators |
Details |
7Seg Display |
| Swing Motors : Qty , Purpose |
Details |
2, Left/right, Up/Down |
| Temperature sensor : Nos & Locations |
Details |
2, air inlet, Eva inlet |
| Other |
Filter Type |
Details |
Regular |
| Power cord & Plug : (Standerd name & version) |
Details |
Yes |
| Connecting wire between IDU & ODU : Length |
ft |
16.4 |
| Connecting tube(CU with insulation) between IDU & ODU : Length |
ft |
12 |
| General |
Outdoor side noise level (Hi/Mi/Lo) |
dB(A) |
59-Turbo; 58-High |
| Dimension : L*W*H (Including foot & service valve) |
mm |
771 x 320 x 552 |
| Packing : L*W*H |
mm |
820 x 360 x 625 |
| Weight : Net & Gross |
Kg |
35±1 & 38±1 |
| Max. discharge/Suction pressure |
MPa |
4.15/1.15 |
| Compressor |
Preferred Model |
Details |
Samsung-UG8CH8180DJH |
| Type : Fixed speed / Inverter |
Details |
Fixed Speed |
| Locked rotor Amp(LRA) |
A |
46.0 A at 220 V |
| Thermal protector |
Yes/ No |
No |
| Over load Protector (Location) |
Details |
internal |
| Capacitor (If applicable) |
uF |
45 |
| Fan motor |
Motor Type : Single Phase Induction |
Details |
Induction |
| Motors Mechanical output Wattage |
Watt |
35 |
| Capacitor |
μF |
3 |
| Outdoor Fan speed |
R/min |
850 |
| Thermal protector |
Yes/ No |
Yes |
| Fan |
Dimensions (Dia* Hight) |
mm |
Φ400, H-115 |
| Number of Blades |
No’s |
3 |
| Material of Blades |
Details |
ABS 20%GF |
| Condenser |
Rows*Tubes |
No’s |
2*24 |
| Tube pitch(a)x row pitch(b) |
mm |
21 x 12.7 |
| Coil length |
mm |
722 OR; 703 IR |
| Tube outside & Inside diameter |
mm |
ODΦ7.0 x 0.25 x0.18 IGT |
| Tube Material & Grade |
Details |
DHP COPPER, C12200 |
| Fin spacing |
mm |
1.2 |
| Fin Type |
Details |
Bare |
| Fin Material |
Details |
Aluminum |
| Expansion device |
Capillary/EEV |
|
Capillary |
| Length (IF capillary) |
mm |
325 |
| Diameter( Inside & Outside) (IF capillary) |
mm |
IDΦ1.6 x ODΦ3.0 |
| Material (IF capillary) |
Details |
Copper Tube |
| Other |
Gas/ Refrigerant Type |
Details |
R-410a |
| Gas/ Refrigerant Qty |
Grams |
1000 |
| Yes/No |
Pcs |
Yes |
| RF / IR Based |
Details |
IR |
